二通道专业功放 |
MS600 |
MS800 |
MS1000 |
MS1200 |
MS1500 |
|
|
|
|
|
|
|
|
机身尺寸(mm) |
482×495×88 |
482×470×133 |
482×470×133 |
482×535×133 |
482×535×133 |
|
重量 |
22KG |
26KG |
26KG |
37KG |
42KG |
|
输出功率 |
|
|
|
|
|
|
8Ω |
2×600W |
2×800W |
2×1000W |
2×1200W |
2×1500W |
|
4Ω |
2×1200W |
2×1600W |
2×2000W |
2×2400W |
2×3000W |
|
|
|
|
|
|
|
|
三通道专业功放 |
MT950 |
|
MT1600 |
|
|
|
|
|
|
|
|
|
|
机身尺寸(mm) |
482×495×88 |
|
482×470×133 |
|
|
|
重量 |
22KG |
|
29KG |
|
|
|
输出功率 |
|
|
|
|
|
|
8Ω |
2×280W+500W |
|
2×500W+800W |
|
|
|
4Ω |
2×560W+1000W |
|
2×1200W+1600W |
|
|
|
|
|
|
|
|
|
|
技术参数 |
|
|
|
|
|
|
|
|
|
|
|
|
|
频率响应 |
20HZ-25KHZ±0.5db |
|
|
| |
|
THD+N(Rated power,4Ω/KHZ)% |
0.10% |
|
|
|
|
|
信噪比 |
95db |
|
|
|
|
|
连接方式 |
|
|
|
|
|
|
输入方式 |
3-pin XLR,平衡式 |
|
|
| |
|
输入阻抗 |
20KΩ平衡/10KΩ非平衡 |
|
|
| |
|
输出连接 |
speakon Connectors(Neutrik) |
|
|
| |
|
电压 |
|
|
|
|
|
|
电压要求 |
200-240V/50-60HZ |
|
|
| |
